Pi30系列产品拥有640x480和384x288两种分辨率规格可供选择，测温领域可达-20°C~2000°C，使其可能适应分歧的利用场景 。同时，可供选择的长焦镜头和广角镜头也可以为OEM集成商/用户带来更多方便 。
|
镜头名称
镜头参数 |
尺度镜头
|
广角镜头
|
长焦镜头
|
|
|---|---|---|---|---|
| Pi33L |
视场角(FOV)
|
25° x 18.7°
|
50° x 37.5°
|
12° x 8.9°
|
|
空间分辨率(IFOV)
|
1.13mrad
|
2.07mrad
|
0.57mrad
|
|
|
最幼聚焦距离
|
0.3m
|
0.3m
|
1m
|
|
|
镜头焦距
|
15mm
|
8.2mm
|
30mm
|
|
| Pi36L |
视场角(FOV)
|
25° x 18.7°
|
50° x 37.5°
|
12° x 8.9°
|
|
空间分辨率(IFOV)
|
0.68mrad
|
1.31mrad
|
0.34mrad
|
|
|
最幼聚焦距离
|
0.3m
|
0.3m
|
1m
|
|
|
镜头焦距
|
25mm
|
13mm
|
50mm
|
|
| Pi33H |
视场角(FOV)
|
25° x 18.7°
|
50° x 37.5°
|
12° x 8.9°
|
|
空间分辨率(IFOV)
|
1.13mrad
|
2.32mrad
|
0.53mrad
|
|
|
最幼聚焦距离
|
0.5m
|
0.5m
|
1.5m
|
|
|
镜头焦距
|
15mm
|
7.34mm
|
32.2mm
|
|
| Pi36H |
视场角(FOV)
|
25° x 18.7°
|
50° x 37.5°
|
12° x 8.9°
|
|
空间分辨率(IFOV)
|
0.67mrad
|
1.39mrad
|
0.32mrad
|
|
|
最幼聚焦距离
|
0.5m
|
0.7m
|
5m
|
|
|
镜头焦距
|
25.3mm
|
12.2mm
|
53.9mm
|
